Scanning Services

  Clean, production-ready CAD files at a fraction of the price!
Need CAD files of your original printed circuit board? If you are reproducing a PCB board or want a digital version (DXF) of the original file then let us serve you. We scan and digitalize your original artwork and convert it into 100% perfect CAD quality data (i.e. flashed pads & single line format). We pride ourselves on providing clean, production-ready CAD files at a fraction of the cost of our competitors.

    DXF gerber conversion
  • AutoCAD gerber conversion (complete data output formats at the bottom of this page)
  • Scan media: paper, diazo, silvers, raw circuit boards (complete input formats at the bottom of this page)
  • High resolution, 4000 dpi, calibrated scanner
  • Standard 2-3 day turnaround; Same day and 24 hr. service available
  • 15 minute quotations - we understand your time is valuable!
  • 100% Satisfaction Guarantee

For an immediate price quotation, e-mail board information (size, layer count, mask, silk, & other pertinent specifications) and a media format attachment to

Or you can request a quotation by faxing a copy of the bare board (1 circuitry side from either side of the board). Please list board information on size, layer count, mask, silk, & other pertinent specifications on a separate page of the fax to:
Fax: (303) 651-9758.

> We'll convert your artwork to 100% perfect, good as new CAD data.

Judge By the Numbers
The above examples represent half inch segments. The "Raw Scan Data" has 877 individual, 0.12 inch lines or when translated into a 5 x 7 inch board this becomes roughly 122,780 lines of data. Compare this to the "Final, Clean CAD Data" which represents only 1,540 lines of data for the same 5 x 7 inch board. Many of our competitors produce only raw scan data as final output. The bottom line is that raw scan data with increased data size is inaccurate and can slow down processing in your CAM department or board shop. It can even crash your plotter and CAD system.

Data Input Formats   Data Output Formats
  • Paper
  • Film
  • Vellum
  • Microfilm
  • Bare Board
  • Drawings
  • Metal
  • PDF
  • Bitmap: .tif, .eps, .bmp, .jpg, etc.
  • AutoCAD
  • HPGL
  • Orbotech
  • Call us to discuss other options!
  • DXF (AutoCAD)
  • Gerber / CNC Drill Files
  • HPGL
  • Orbotech
  • Genesis 2000
  • Call us to discuss other options!
